Detail Specifications
For wire processing
Features:
■Control panel in Chinese and English for easy, smooth operation.
■Modular molds for flexible processing.
■Standard wire loader: 1,500kg.
Model:WB-380
Wire dia.: 3.0mm~8.0mm (metallic wire 1006)
No. of shaft: 3 standard; 4 shafts max.
Working range: 700 x 700 x 700 (mm)
Wire feed: max. speed 70m/min;
max. feed length +/-99999999
Curve:
bending degree 360°;
bent R 3.0mm-10.0mm
PC: G-code industrial PC
Power: 220V, 3-phase
Weight: 1,100kgs
Dimensions: 265 x 80 x 160 (cm)
Movie:
https://www.youtube.com/watch?v=d4mKGyn_RP0&t=5s
